Aluminium sheets are versatile and widely used due to their high strength, corrosion resistance, and workability. They are lightweight and suitable for various industrial, structural, and decorative applications.
Here are some of the types of Aluminium Sheets.
Description: Aluminium 1100-H14 is a commercially pure aluminium grade, known for its excellent corrosion resistance, high thermal and electrical conductivity, and excellent workability. This grade is non-heat-treatable and maintains good mechanical properties, making it suitable for a variety of industrial applications.
Specifications:
Chemical Composition:
- Aluminium (Al): 99.0% min
- Copper (Cu): 0.05-0.20%
- Iron (Fe): 0.95% max
Mechanical Properties:
- Tensile Strength: 110-145 MPa
- Yield Strength: 105 MPa
Physical Properties:
- Density: 2.71 g/cm³
- Thermal Conductivity: 222 W/m·K
Uses:
Industrial Applications:
- Heat exchangers
- Chemical equipment
Consumer Goods:
- Cooking utensils
- Light reflectors
Description: Aluminium 3003-H14 is an aluminium-manganese alloy that offers a good balance of strength and workability. It is characterized by its excellent corrosion resistance, especially in environments where moisture is present. This alloy is non-heat-treatable but maintains a higher strength compared to 1100.
Specifications:
Chemical Composition:
- Aluminium (Al): 96.7% min
- Manganese (Mn): 1.0-1.5%
- Copper (Cu): 0.05-0.20%
Mechanical Properties:
- Tensile Strength: 130-180 MPa
- Yield Strength: 120 MPa
Physical Properties:
- Density: 2.73 g/cm³
- Thermal Conductivity: 163 W/m·K
Uses:
Construction:
- Roofing sheets
- Cladding
Industrial:
- Heat exchangers
- Storage tanks
Description: Aluminium 5052-H32 is a high-strength, non-heat-treatable alloy with exceptional corrosion resistance, particularly in marine environments. It is known for its excellent weldability and moderate-to-high strength, making it suitable for a wide range of applications.
Specifications:
Chemical Composition:
- Aluminium (Al): 95.7-97.7%
- Magnesium (Mg): 2.2-2.8%
- Chromium (Cr): 0.15-0.35%
Mechanical Properties:
- Tensile Strength: 210-260 MPa
- Yield Strength: 130 MPa
Physical Properties:
- Density: 2.68 g/cm³
- Thermal Conductivity: 138 W/m·K
Uses:
Marine:
- Boat hulls
- Marine fittings
Automotive:
- Fuel tanks
- Pressure vessels
6061-T6
Description: Aluminium 6061-T6 is a heat-treatable alloy known for its high strength, excellent corrosion resistance, and good mechanical properties. It is versatile and widely used in a variety of structural and engineering applications. This alloy is also known for its good weldability and machinability.
Specifications:
Chemical Composition:
- Aluminium (Al): 95.85-98.56%
- Magnesium (Mg): 0.8-1.2%
- Silicon (Si): 0.4-0.8%
Mechanical Properties:
- Tensile Strength: 310 MPa
- Yield Strength: 275 MPa
Physical Properties:
- Density: 2.70 g/cm³
- Thermal Conductivity: 170 W/m·K
Uses:
Structural:
- Bridges
- Frames
Aerospace:
- Aircraft components
- Truck frames
Description: Aluminium 7075-T6 is a high-strength, heat-treatable alloy primarily used in aerospace and military applications. It offers excellent fatigue resistance and is known for its toughness. This alloy is often used where high strength and low weight are critical.
Specifications:
Chemical Composition:
- Aluminium (Al): 87.1-91.4%
- Zinc (Zn): 5.1-6.1%
- Magnesium (Mg): 2.1-2.9%
Mechanical Properties:
- Tensile Strength: 510-540 MPa
- Yield Strength: 430-480 MPa
Physical Properties:
- Density: 2.81 g/cm³
- Thermal Conductivity: 130 W/m·K
Uses:
Aerospace:
- Aircraft structures
- Gears
Military:
- Defense equipment
- Firearm components
