Aluminium square bars are versatile and strong, known for their excellent corrosion resistance and machinability. They are used in various structural, industrial, and engineering applications due to their durability and lightweight properties.
Description: Aluminium 6061-T6 is a versatile, heat-treatable alloy known for its high strength, excellent corrosion resistance, and good machinability. It is widely used in structural and engineering applications.
Specifications:
Chemical Composition:
- Aluminium (Al): 95.85-98.56%
- Magnesium (Mg): 0.8-1.2%
- Silicon (Si): 0.4-0.8%
Mechanical Properties:
- Tensile Strength: 310 MPa
- Yield Strength: 275 MPa
Physical Properties:
- Density: 2.70 g/cm³
- Thermal Conductivity: 170 W/m·K
Uses:
- Structural supports
- Frames and brackets
- Aerospace components
- Automotive parts
Description: Aluminium 7075-T6 is a high-strength, heat-treatable alloy known for its exceptional fatigue resistance and toughness. It is used in demanding applications where high strength and durability are critical.
Specifications:
Chemical Composition:
- Aluminium (Al): 87.1-91.4%
- Zinc (Zn): 5.1-6.1%
- Magnesium (Mg): 2.1-2.9%
Mechanical Properties:
- Tensile Strength: 510-540 MPa
- Yield Strength: 430-480 MPa
Physical Properties:
- Density: 2.81 g/cm³
- Thermal Conductivity: 130 W/m·K
Uses:
- Aircraft structures
- Defense equipment
- High-stress applications
- Automotive components
Description: Aluminium 2024-T351 is an aluminium-copper alloy known for its high strength and excellent fatigue resistance. It is used in aerospace and other high-performance applications.
Specifications:
Chemical Composition:
- Aluminium (Al): 90.7-94.7%
- Copper (Cu): 3.8-4.9%
- Magnesium (Mg): 1.2-1.8%
Mechanical Properties:
- Tensile Strength: 470-510 MPa
- Yield Strength: 325-370 MPa
Physical Properties:
- Density: 2.78 g/cm³
- Thermal Conductivity: 121 W/m·K
Uses:
- Aircraft components
- Truck wheels
- Hydraulic systems
- Structural applications
Description: Aluminium 6082-T6 is a heat-treatable alloy known for its good corrosion resistance, weldability, and strength. It is commonly used in applications that require medium to high strength and resistance to stress corrosion.
Specifications:
Chemical Composition:
- Aluminium (Al): 95.2-98.3%
- Magnesium (Mg): 0.6-1.2%
- Silicon (Si): 0.7-1.3%
Mechanical Properties:
- Tensile Strength: 290-340 MPa
- Yield Strength: 250-300 MPa
Physical Properties:
- Density: 2.70 g/cm³
- Thermal Conductivity: 180 W/m·K
Uses:
- Trusses
- Bridges
- Cranes
- Transportation structures
Description: Aluminium 5083-H112 is a high-magnesium alloy with outstanding resistance to corrosion, particularly in marine environments. It offers good weldability and is used in applications exposed to harsh conditions.
Specifications:
Chemical Composition:
- Aluminium (Al): 92.1-94.6%
- Magnesium (Mg): 4.0-4.9%
- Manganese (Mn): 0.4-1.0%
Mechanical Properties:
- Tensile Strength: 275-350 MPa
- Yield Strength: 215 MPa
Physical Properties:
- Density: 2.66 g/cm³
- Thermal Conductivity: 121 W/m·K
Uses:
- Shipbuilding
- Marine structures
- Pressure vessels
- Cryogenic tanks
